____________________________________________________ Maintenance Every 3 months electric motor
Lubricate the feeder breaker’s electric motor through the two (2) grease fittings located on the central lubrication panel (Fig. 40) located on the right side of the discharge section. Pump only one or two pumps of grease into each fitting. NOTICE! Incorrect grease or over greasing may cause serious damage to the electric motor.
reducer
Lubricate the reducer through the two (2) grease fittings located on the central lubrication panel (Fig. 40) located on the right side of the discharge section. Pump only one or two pumps of grease into each fitting. Fig. 40: Electric motor and reducer lubrication Reducer central lubrication panel
torque limiter
Electric motor central lubrication panel
Check torque limiter clutch disk wear as shown. Clutch disk must be changed when 3.46” is measured as shown in Fig. 41. Fig. 41: Torque limiter clutch wear 3.55” New thickness 3.46” Worn thickness
______________________________________________________________ REV 2 5.59
