Page 27

2 - SAFETY INFORMATION

During the movements, keep the bucket as low as possible at all times. Drive the machine with the headlights on and use appropriate signals and flags. Know and observe local regulations. Use a ramp to load the machine onto a transport vehicle. Ramps should be sufficiently strong to support the weight of the machine. Load and unload the machine onto the transport vehicle always on a level surface.

ENGINE Do not leave the engine running in an enclosed area without proper ventilation capable of removing harmful gases. Keep hands away from the belts and fans. When topping up the radiator coolant level, loosen the radiator cap slowly to release the pressure. Remove the cover after making sure that there is no more pressure. Do this operation only with the engine turned off. Prevent flammable materials from coming into contact with the exhaust system. Do not refuel the machine with the engine running, especially if it is hot. This procedure increases the risk of fire in case of fuel spillage.

Do not run the engine with the air inlets open or without the air filter. Engine startup 1. Do not increase the engine speed shortly after turning it on, so as not to damage the lubrication of the turbocharger bearings. 2. Start the engine and let it run at half the maximum rotation for 3 to 4 minutes before placing the machine in operation. Stopping the engine Before shutting down the engine, let it to run for a few minutes at idle speed to allow for deceleration and stabilization of the turbocharger at a low speed and temperature. Never increase the engine speed before you shutting it down so as not to damage the journals of the turbocharger through lack of lubrication. If the engine is turned off suddenly at high rotation, the turbocharger will continue to rotate after the engine oil pressure lowers to zero. Running at high speed without oil, the journals of the turbocharger will be damaged in a matter of seconds.

2-7
