OPERATING INSTRUCTIONS
!
WARNING : In the normal travel position, the operator’s compartment is above the idler wheels and the travel reduction gears are to the rear of the upperstructure. If the upperstructure is turned 180° in relation to the undercarriage, lever functions are reversed.
Traveling in a straight line (in reverse)
IMPORTANT : Before undertaking any travel, raise the attachment and the dozer blade.
Traveling in a straight line (forwards) CS98M547
Template Name: OM_1_col Template Date: 1994_04_29
Press the two pedals (or push the two levers) rearwards at the same time.
TRIM THIS EDGE
NOTE : Travel speed depends on the tilting angle of the travel control levers and pedals and the speed travel mode selected. See “Travel speed selector pedal” in the “Controls/Instruments/Accessories” Section.
Alt= to hide template information Alt+ to display template information
MACHINE TRAVEL
CS98M546
Press the two pedals (or push the two levers) forwards at the same time.
89
