OPERATING INSTRUCTIONS
IMPORTANT : Normal operating temperature of the hydraulic fluid is between 50°C and 80°C. If the machine is used with the hydraulic fluid at a temperature below 20°C, the damage can be caused.
Engine manual warm-up
Hydraulic oil warm-up
With the engine throttle button a quarter open, start the engine and allow it to run approximately 5 to 10 minutes. Then follow the procedure for bringing the hydraulic fluid up to operating temperature.
Turn the engine throttle button to halfopen position. Operate the bucket control slowly until the bucket is completely closed. Operate the dipper retracting control slowly until the dipper is completely retracted and hold the control in this position for 30 seconds. During this time the temperature of the hydraulic fluid will increase. After 30 seconds, extend the dipper completely and hold the control in this position a further 30 seconds. Continue the extending and retracting procedure until the temperature rises.
TRIM THIS EDGE
After starting the engine and before using the machine, allow the hydraulic fluid to reach a temperature of 20°C.
Alt= to hide template information Alt+ to display template information
BRINGING THE MACHINE UP TO OPERATING TEMPERATURE
Template Name: OM_1_col Template Date: 1994_04_29
Operate the travel and attachment controls three or four times to activate hydraulic fluid circulation.
