CONTROLS/INSTRUMENTS/ACCESSORIES
LOWER PANELS Template Name: OM_1_col Template Date: 1994_04_29
These panels are located under the upperstructure frame and give to certain machine components. IMPORTANT : Do not operate the machine with the panels removed.
CP99A006
!
WARNING : Before undertaking any travel, make sure the panels are correctly locked.
TRIM THIS EDGE
WINDSHIELD WASHER RESERVOIR IMPORTANT : Never operate the windshield washer control when the reservoir is empty. This could cause damage to the electric pump. Remove the cap to fill the reservoir.
Alt= to hide template information Alt+ to display template information
NOTE : In cold weather, add anti-freeze to the windshield washer water.
CK98M020
This reservoir, located on the left in the engine compartment, is equipped with an electric pump which is operated from the right-hand control arm. See item 4 under “Right-hand control arm”.
70
