LUBRICATION/FILTERS/FLUIDS
ENGINE Service specifications Template Name: OM_1_col Template Date: 1994_04_29
Engine oil level check .................................................Every 10 hours or every day Oil change ..................................................................................... Every 200 hours (After the first 50 hours of operation) Oil filter replacement ..................................................................... Every 400 hours (After the first 50 hours of operation) Oil type ..........................................................................See “Fluids and lubricants” Oil capacity ................................................................................................ 6.8 litres
Level STEP 3
STEP 1 Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key.
B
TRIM THIS EDGE
STEP 2
A
CS98M579
Alt= to hide template information Alt+ to display template information
CK98M024
When the engine has been stopped for fifteen minutes, remove the dipstick, wipe it with a clean cloth and replace it in the guide tube as far as it will go. Then take it out again. CK98M024
If the oil level is below the mark (A) (minimum), remove the oil filler cap, add oil up to the mark (B) (maximum) on the dipstick and then replace the oil filler cap. NOTE : The level should not be higher than the mark (B) (maximum) on the dipstick. 138
