CONTROLS/INSTRUMENTS/ACCESSORIES
ACCESS PANELS
The access panels must be removed to perform service work.
PG02727
To remove the central panel, unlock the handle located in the panel hole and pull the panel backwards.
Central panel
Side panels
PH08006
PH08003
The central panel gives access mainly to the engine components.
The left-hand panel gives access to the anti-surge valve, the shut-off valve and to the hydraulic reservoir drain plugs.
75
TRIM THIS EDGE
RIGHT PAGE
TRIM THIS EDGE
PH08215
To gain better access to components, place the upperstructure at right angles to the undercarriage.
Template Name: OM_1_col Template Date: 1994_04_29
- One 17 wrench for hexagonal head screws
Alt= to hide template information Alt+ to display template information
Tools required
