STORAGE
STORING THE MACHINE Template Name: OM_1_col Template Date: 1994_04_29
The following procedure is to be used for storing the machine for a period of one month or more.
Preparation for storage 1.
Park the machine on a flat, horizontal and clean surface.
2.
Grease the whole machine.
3.
Fully retract the dipper cylinder.
4.
Grease the exposed surfaces of cylinder rods or coat them with a protective film (Aerosol spray ref. S1403568).
NOTE: When the machine resumes service the film will disappear automatically.
TRIM THIS EDGE
5.
Release the pressure in the hydraulic system.
6.
Clean the outer parts of the engine with diesel fuel.
7.
While the engine is still warm, drain the oil sump and fill the engine with anticorrosive oil up to the MAX mark on the dipstick.
8.
Drain the fuel tank and fill with a mixture of 90% diesel fuel and 10% anticorrosive oil.
9.
Run the engine at idle speed for five minutes to allow the anti-corrosive oil to reach the lines, filters, pump, turbocharger and injectors.
Alt= to hide template information Alt+ to display template information
10. Remove the rocker arm covers. Spray a mixture of 90% diesel fuel and 10% anti-corrosive oil into the rocker arm chamber. Install the rocker arm covers. 11. Plug the air filter intake port and the exhaust pipe. 12. Disconnect the electrical system using the battery master switch. 13. Remove the batteries.
266
