MAINTENANCE/ADJUSTMENTS STEP 7
STEP 5
Template Name: OM_1_col Template Date: 1994_04_29
CD98D034
Start the engine and retract the bucket cylinder. STEP 6
CD98D033
Using a screwdriver, remove the bucket/ dipper linkage pin locking pin. Remove the bucket/dipper connecting pin. STEP 8
TRIM THIS EDGE
Alt= to hide template information Alt+ to display template information
CD98D034
Raise the attachment to balance the bucket. Lower the bucket to the ground again, shut down the engine and remove the starter switch key.
CD98D032
Start the engine. Move the attachment controls so as to free the dipper from the bucket.
!
WARNING: The tube placed to immobilise the bucket ejector must never be removed while the bucket is not being used.
IMPORTANT: It is essential for the ejector to remain immobilised during any transport or handling of the bucket.
232
