LUBRICATION/FILTERS/FLUIDS
STEP 3
CD98G040
Clean any dirt from the pre-filter head. Install the new filter element, complete with its bowl. Make sure it is correctly oriented by aligning the vertical mark with the bleed screw. Insert the filter element, pushing it gently upwards. Turn the knurled ring until it clicks. STEP 5
TRIM THIS EDGE
CD98G040
Clean around the sediment bowl, then remove the bowl from the filter element, unscrewing it by hand.
Alt= to hide template information Alt+ to display template information
STEP 4
STEP 2
CD98G040
Loosen the bleed screw a few turns.
179
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
CD98G040
Remove the drain screw and its seal supplied with the new element. Check the condition of the sediment bowl seal, change it if necessary, apply a thin film of oil to the seal, then install the sediment bowl on the new filter element, tightening it by hand.
