OPERATING INSTRUCTIONS
HANDLING THE MACHINE Template Name: OM_1_col Template Date: 1994_04_29
1
2
This decal shows the position of the centre of gravity in relation to the travel reduction gear centre-line. The centre of gravity distance (D) varies depending on the three possible handling configurations for the machine.
3
(1) Machine without boom, without cab and without counterweight. (2) Machine without boom, with cab and with counterweight. CS98M643
(3) Machine with monoblock boom, with cab and with counterweight.
NOTE: Machine weights are given with 0.60 m track pads.
TRIM THIS EDGE
!
WARNING: The fixing points shown in the above decal must be observed.
788 series CK type Distance (D)
Machine weight
(1)..................................................... 1.206 m .............................................8814 kg (2)..................................................... 0.809 m ..........................................12 059 kg (3)..................................................... 1.086 m ..........................................13 316 kg
Alt= to hide template information Alt+ to display template information
788 series LC type Distance (D)
Machine weight
(1)..................................................... 1.359 m .............................................9476 kg (2)..................................................... 0.984 m ..........................................12 291 kg (3)..................................................... 1.238 m ..........................................14 248 kg
988 series CK type Distance (D)
Machine weight
(1)..................................................... 1.270 m ..........................................10 892 kg (2)..................................................... 0.808 m ..........................................14 778 kg (3)..................................................... 1.161 m ..........................................16 448 kg
106
