LUBRICATION
SUPPORT STRUT FOR LOADER LIFT ARMS Carry out these procedures with 2 people to avoid entering and exiting the operators compartment under a raised bucket. WARNING: If you service the machine with the loader lift arms raised, always use the support strut: Empty the loader bucket, raise the loader lift arms to maximum height and stop the engine. Remove the rear pin from the support strut and lower the support strut onto the cylinder rod. Install the rear pin in the support strut. Slowly lower the lift arms onto the support strut. If you do not follow this procedure, you can cause serious injury or death if the loader lift arms are lowered by accident. SA068
Installing the Support Strut 4. Lower the loader lift arms onto the support strut. Install the rear pin.
1. Lower the loader lift arms to the ground and stop the engine.
TRIM THIS EDGE
2. Remove the rear pin.
BP96C014 BP96C018
3. Start the engine and raise the loader lift arms until the support strut is on the lift cylinder rod.
Continued on next page
66
