ADJUSTMENTS/MAINTENANCE
TILTING THE OPERATORS COMPARTMENT FORWARD 1. Start the engine and run at idle speed.
5. Disconnect the seat bar locking mechanism on each side.
TRIM THIS EDGE
BP96C016
BP96C038
2. Raise the loader lift arms to full height and install the support strut.
NOTE: The seat can stay with the ROPS when you rotate the ROPS forward. Do step 6 if you want to remove the seat.
3. Stop the engine and raise the seat bars
6. OPTIONAL: Loosen and remove the two bolts that fasten the seat to the operators compartment and remove the seat.
4. Loosen and remove the bolts, lock wa she rs an d flat w as he rs th at fasten the operators compartment to the po sts on th e re ar o f th e machine.
7. Use the grab handles and pull the compartment all the way forward.
BP96C055 BP96C039
98
