LIFTING THE EXCAVATOR
Figure OI-162
Procedure Figure OI-161 2
2
1 1
B-16594
Fully extend the cylinders of the bucket, arm & boom so that the excavator is in the position shown [Figure OI161].
Fasten a chain to the boom (Item 2) [Figure OI-161] & [Figure OI-162] and up to a lifting fixture.
Raise the blade all the way. Put the all control levers in neutral. Stop the engine and exit the excavator.
85 of 166
OI-61
442 Operation & Maintenance Manual
Dealer Copy -- Not for Resale
Fasten chains to the ends of the blade (Item 1) [Figure OI-161] & [Figure OI-162] and up to a lifting fixture above the cab. The lifting fixture must extend over the sides of the cab to prevent the chains from hitting the cab.
P-32909
