BMW Dl 2 Marine engine REMOVING AND INSTALLING THE DECOMPRESSION LEVER
C
Removing the decompression lever —
Remove the cylinder head
Fig. 42 Knock the spring pin out of the decompression shaft (42/1).
42
C
Fig. 43 Turn over the cylinder head, screw out the headless screw (43/1) and remove the spring (43/2). This frees the shaft.
C
43 Fig. 44
fl La
C
Disengage the two circlips (44/1) from the shaft and use a suitable drift to knock the shaft out of the cylinder head.
~J0
If
C 44 22
