Removing and installing the water pump

Example for calculating the piston projection: Thickness of cylinder-head gasket 1,50 mm Reading obtained —0,65 mm Piston projection = 0,85 mm — Install the cylinder head

REMOVING AND INSTALLING, STRIPPING AND ASSEMBLING THE WATER PUMP

Removing the water pump — Remove the cooling water hoses Fig. 64 Unscrew the two hex.nuts (64/1), remove them together with the spring washers and take the water pump off the crankcase.

Installing the water pump Installation takes place in the reverse sequence to removal.

Fit a new 0-ring (65/17) on the pump flange. 64
