Removing and installing the air filter

REMOVING AND INSTALLING THE AIR FILTER

Removing the air filter

Fig. 22 Undo the three clips (22/1) and take off the filter cover (22/2).

Fig. 23 Remove the filter element, unscrew the two hex. nuts (23/1) and remove the lower part of the filter housing with seal from the cylinder head. 22

Installing the air filter Installation takes place in the reverse sequence to removal. 23
