Removing and installing the starter

REMOVING AND INSTALLING THE STARTER

Removing the starter — Disconnect the electrical leads from the starter

Fig. 6 Loosen the two hex. nuts (6/1) and screw them back as far as they will go, pull back the starter and again unscrew the nuts as far as they will go. Repeat the process until the nuts are fully unscrewed. Remove the washers (6/2) from the threaded bolts and take the starter off the flywheel housing.

Installing the starter Installation takes place in the reverse sequence to removal.

REMOVING AND INSTALLING THE GEARBOX

Removing the gearbox — Remove the retaining plate with engine electricals — Remove the starter

Fig. 7 Unscrew the four hex. nuts (7/1) and take them off together with the washers. Remove the flywheel housing cover (7/2) complete with gearbox from the engine.
