Section F. Adjustments
Belarus - 90/92
Section F. ADJUSTMENTS Front track adjustment Steering booster without hydraulic cylinder in steering linkage Front track can be changed in the range from 1350 to 1850 mm with intervals 100 mm at symmetric and 50 mm at asymmetric wheel arrangement. For arrangement of the required track of guide wheels perform the following operations: а) lift the tractor front part by jack until the wheels break off the ground; b) loosen bolts (1), take out pins (2) mountings of the retractable cams in the tube of front axle; c) at first move the first and then the second retractable cam (6) (simultaneous change the length of steering links by turning tubes (3) in the tips (5), preliminary turning off lock-nuts (4)) at appropriate value of arrangement track and then fix cams in the tube of front axle; d) lower the tractor down. Check toe-in and, if necessary, adjust it.
61
Operating manual
