Section E Ganging up
Belarus – 90/92 Operating Manual
Control of tractor hydraulic system and hitch attachment Hitch attachment on tractors is controlled with extreme right-hand handle of distributor. When operating with mounted machines, use only “lift” and “floating” positions of handle. It is prohibited to set the handle into “lowering” position, when operating with mounted tilling machines! Use “lowering” position only when operating external cylinders, installed on the machine and intended to adjust positions of working devices (reel, header, ploughshares. etc.) of harvesting, seeding and other machines. If distributor handle doesn’t return automatically to “neutral” after termination of cylinder travel, take it out manually. And vice versa, in case of premature return of the handle hold it by hand until operation is fully completed.
Special character of tractor operation with machines that require driving from rear PTO General recommendations: a) Make sure that rear PTO control is properly adjusted before connecting machine to tractor; b) Install and fasten securely required (6, 8- or 21-splined) PTO drive end and actuate drive of rate speed corresponding to it. Set 540 rpm for 6, 8-splined drive end, and 1000 rpm for 21-splined drive end.
51
