Section E Ganging up
Belarus – 90/92 Operating Manual
Mounting machinery on tractor 1. Before mounting machine on the tractor, first make sure there are no people in the machine mounting zone. 2. Using draft control lever (if installed), lower the hitch attachment into down position, pull tractor back and hinge the machine to lift links. Fasten the pins by cotters. Shut down the engine. 3. Extend or shorten the top link (1) and couple the hitch ball to the machine. Fasten the pin by cotter. 4. If necessary, set the top link to initial or required length. 5. If necessary, make lateral machine tilt adjustment by means of right-hand adjustable brace (2). To increase length of the brace turn lever (3) clockwise, and visa versa. 6. Before starting work make sure that: • Parts of the tractor are not in dangerous proximity to machine elements; • Top link is not in contact with PTO guard, when machine is in lowermost position; • Cardan drive from PTO is not too long, has no wide joints’ angles, and there are no thrust forces; • PTO guard is not in contact with the guard of machine cardan drive. 7. Slowly lift the machine and make sure that clearances between the wheel and machine in lifted position are not less than 100 mm. 8. Check whether the side sway of lift links is sufficient and, if necessary, adjust it by means of ties.
44
