Section E Ganging up
Belarus – 90/92 Operating Manual
Rear hitch attachment Three-point hitch attachment of 2 category provides coupling to tractor mounted and semi-mounted agricultural machinery and implements, having the following coupling elements: • length of suspension axle «L» (distance between joints «А» and «В») equals to 870mm; • height of machine post equals to 510 mm; 610 mm; • diameter of pins for coupling to joints of lift links (1) equals to 28.7 mm; • diameter of pin for coupling to top link (2) equals to 25 mm. ATTENTION! Carefully study this section before coupling machines. Lift links consist of two parts: • front part or the link itself; • rear end with ball joint. Standard length of lift links is 885 mm. To increase the length of suspension install lift ends with bent front joints (F704605050-01/055-01). To increase lifting capacity of hitch attachment replace rear ends of links (of 400 mm long) with lift ends, where the distance between joint pin and front hole is 320mm (N50-4605040А2/045А2). Total length of the lift link will be 805 mm. Attention! If the link length is 805mm, lifting capacity of hitch attachment will increase up to 10%, with simultaneous decrease of lift height by 10%. The same increase of lifting capacity can be provided by installation of brace(1) at additional points (lift height will decrease by 10% as well).
42
В
