Section D. Operation Instruction
Belarus – 90/92
The beginning of tractor movement ATTENTION! When selecting required movement speed use the gear shifting diagram. To put tractor in motion do the following: • Press clutch pedal to the full; • Shift lever (2) to the extreme left position and pull or push it to select I or II mode, correspondingly; • Turn lever back to “neutral” position and then further to the right, select the required gear and pull or push the lever (2) to set selected speed. • Push or pull lever (1) to the required extreme position.*) Disengage the parking brake and increase slightly fuel distribution, smoothly release the clutch pedal. After the movement of the tractor increase fuel distribution. Avoid starting movement at large traction load (like deep plough in soil). ATTENTION! Always press pedal clutch before putting on required range or gear of gear box. Keep the foot off the clutch pedal in the process of tractor operation, as this will result in clutch slippage, overheating and ultimate failure. *)
Pull back – top gear, push forward – speed reducing for the tractors with reducing gear.
39
