Section B. Technical data
Belarus – 90/92
Diesel fuel supply system
Operating manual
Adjustment revision of steering wheel: · tilt steering wheel – from 25° to 40° with locking in 5°; · height clearance – in the range 100 mm. Free play of steering wheel – not more than 25°.
Type: combined, with oil cooler Minimal oil pressure: 0,08 МPа (0,8 kgs/cm2) at 600 rev per min. Safe oil pressure: 0,2…0,3 MPa (2…3 kgs/cm2). Maximal pressure on the cold diesel: up to 0,6 MPa (6 kgs/cm2). Lubrication system capacity: 12 l. Brands of motor oil: - from -40°С to +5°С: М-8DМ; М-8G2, М-8G2К or М43/8G2 (SAE-20, SAE 10W-20); - from +5°С to +50°С: М-10DМ; М10G2; М-10G2К (SAE-30); - all-season oil: SAE 15W-40.
Diesel engine starting system Electric starter 12 V.
Diesel cooling system Type: enclosed, with forced fluid circulation, temperature control using thermostat Normal operation temperature from 80°С to 100°С. Cooling system capacity is 20 l.
Feed system of diesel Fuel pump: four-plunger, in-line, with booster pump. Regulator: mechanical, all-mode.
Clutch Type:
Dry, friction, one-disk. Mechanical drive, closed-circuit Driven disk diameter: 340 mm.
Fuel filters: coarse filter and fine filter (disposable element filter FT 020 - 1117010). Fuel mark: diesel: in summer L-0.2-40, L-0.5-40; in winter З-0.2, З0.5. Fuel capacity: 120 l. Air cleaner: combined, with dry centrifugal air purification) Oil bath capacity of air cleaner: 1,5 l.
Steering control Hydraulic booster type: hydro mechanical Steering gear: worm screw, helical sector and steering booster. Pump cell: gear pump NSh10–3–Л. Pump capacity: 21 l/min. Maximum working pressure in the system: 9,0±0,05 MPa. Oil grades: - from -40°С to+5°С: М-8DM; М-8G2, М-8G2К or М43/8G2 (SAE-20, SAE 10W20); - from +5°С to +50°С: М-10DM; М10G2; М-10G2К (SAE-30); - all-season oil: SAE 15W-40. 18
