Section B. Technical data
Belarus – 90/92
Operating manual
Diesel engine Diesel engine model Type Number of cylinders Method of mixture formation Compression degree (calculated) Diameter of cylinder,mm Piston stroke,mm Displacement volume, l Firing order Cooling system Rated speed, rev/min Maximum rotational speed, rev/min Minimum rotational speed, rev/min Rated power, kW Maximum torque, Nm (kgf·m) Clearance between inlet and outlet valve and rocker on cold diesel, mm Advance angle of fuel injection to UDC , degrees Fuel injection pressure MPa (kgf/cm2)
D-243.1 4-stroke, in-line, with natural aspiration 4 Direct fuel injection 16 110 (4,32) 125 (4,92) 4,75 (290) 1-3-4-2 fluid 2200 2380 600 61 at 2200 revolutions per minute 296,9 (30,3) at 1400 revolutions per minute 0,25…0,30 20±1/16±1 21,6…22,4 (220…228)
17
