Section I. Tractor transportation
Belarus 90/92
Operating manual
Section I. TRACTOR TRANSPORTATION AND TOWING Tractors are transported by railroad, motor vehicles, on trailers, as well as by towing or under its own power.
Tie steel ropes down to front axle beam or eye-bolt (1) and rear axle eye-bolt (1), as shown in the diagram below. When steel rope is fastened to eye-bolt (1), put loadgripping mechanism around eye-bolt body and fix it with lock (2) via eye-bolt.
While in transit: • Shift GB levers to the first gear; • Engage reducing gear; • Engage parking reserve brake; • Fasten tractor to platform with 6 mm thick wire, chains, braces.
The lug fixed to front ballast weights and weight arm is provided for connecting towing steel rope. Observe traffic regulations while towing tractor.
During tractor loading/unloading use lifting mechanisms with load-carrying capacity of at least 10 ton-force.
Attention! When lifting tractor by eye-bolts, it can move forward (backwards) up to 1.5 m. .
Don’t use towing shackle to lift tractor.
115
