Removing the Switch Cover CAUTION: Using tools to remove the Switch Cover may cause damage to the outer casing. It is recommended that only fingers are used to remove the Switch Cover. 1. See “Removing the Battery Pack” on page 50. 2. Place the computer on a clean dry surface. 3. Locate and remove the ten securing screws on the bottom of the computer.
Step Switch Cover
Size M2.5*6.5-I (BZN(NYLOK-RED)
Quantity
Screw Type
10
4. Turn the computer over and open the LCD module to expose the Switch Cover. IMPORTANT:The LCD module does not fully extend. Damage will occur if you attempt to extend the LCD module beyond the manufacturer’s design. 5. Lift the Switch Cover as shown, and place over the keyboard. IMPORTANT:Do not remove at this point. FFC cables are still attached on the underside.
66
Chapter 3
