Removing the Optical Disk Drive Module 1. See “Removing the Battery Pack” on page 50. 2. Remove the Lower Cover. See “Removing the Lower Covers” on page 53. 3. Remove the screw securing the ODD module.
Step ODD Module
Size M2.5*6.5-I (BZN(NYLOK-RED)
Quantity
Screw Type
1
4. Grasp the ODD module as shown and pull out of the bay.
Chapter 3
61
