Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
Phoenix SecureCore(tm) Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1: IDE HDD: ST9320320AS 2: IDE CD: Optiarc BD ROM BC-5500S-(S 3: PCI LAN: Atheros Boot Agent 4: USB HDD: 5: USB CDROM: 6: USB FDC: 7: USB KEY: 8: Excluded from boot order: 7: IDE HDD: TOSHIBA MK3252GSX-(S5)
F1 Help ESC Exit
Chapter 2
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSub-Menu
Keys used to view or configure devices: Up and Down arrows select a device. <> and <> moves the device up or down. <f> and <r> specifies the device fixed or removable. <x> exclude or include the device to boot. <Shift + 1> enables or disables a device. <1 - 4> Loads default boot sequence. F9 Setup Defaults F10 Save and Exit
39
