21. Take out the CCD hinge from the CCD cover as well. 22. Disconnect the CCD cable from the CCD board. 23. Remove the two screws fastening the left LCD bracket to the LCD.
24. Remove the left LCD bracket. 25. Remove the two screws holding the right LCD bracket.
26. Remove the right LCD bracket. 27. Tear off the mylar fastening the LCD cable and disconnect the LCD cable from the LCD.
Disassembling the External Modules HDD Module
75
1.
Remove two screws holding the HDD bracket to the HDD.
2.
Remove another two screws fastening HDD bracket to HDD on the other side.
3.
Carefully detach the HDD from the bracke.t
Chapter 3
