11. Disconnect the microphone cable and the touchpad board cable from the main board. 12. Disconnect the LCD cable from the main board. 13. Take out the microphone cable from the upper case.
14. Pull out the wireless antenna set from the back side. 15. Remove the four screws holding the LCD module. 16. Detach the LCD module from the laptop.
Disassembling the Main Unit Separating the Upper Case and the Lower Case
69
1.
Remove the nine screws holding the upper case and the lower case assembly on the front side.
2.
Remove the 16 screws fastening the upper case and the lower case assembly on the bottom side.
3.
Turn over the main unit and disconnect the bluetooth cable from the main board.
4.
Disconnect the power board cable from the main board on the bottom side.
5.
Carefully detach the upper case assembly from the lower case assembly.
Chapter 3
