Security Info.
Main
PhoenixBIOS Setup Utility Security Advanced
Supervisor Password is:
Clear
User Password is:
Clear
SATA Port 0 Disk Status
Clear Supervisor Password controls accesses of the setup utility.
[Enter] [Enter]
Set SATA Port 0 HDD Password
[Enter]
Password on boot:
[Disabled]
Esc Exit
↑ ↓ ←→
Exit
Item Specific Help
Set Supervisor Password Set User Passord
F1 Help
Boot
Select Item
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub-Menu
F10 Save and Exit
The system supports three levels of password protection. The password support consists of a Supervisor Password, User Password, and Hard Disk Password. All the passwords are stored in a non-volatile storage device (EEPROM). • Password Policy:
All the passwords will obey the following rules: • All the passwords can be set or cleared in BIOS Setup Security screen. • The password entry consists of eight alphanumeric characters. At least one character must be assigned. • The valid keys are listed in the table below:
54
Symbol Character
Symbol Name
A-Z
letters A to Z (not case sensitive)
0-9
numerical characters
-
dash
=
equal sign
[
left bracket
]
right bracket
.
period
,
comma
;
semi-colon
/
slash Chapter 2
