Information PhoenixBIOS Setup Utility . Info.
Main
CPU Type: : CPU Speed :
Advanced
Security
Boot
Exit
AMD Turion(tm) 64 X2 Mobile Technology TL-60 2000 MHz
IDE1 Model Name: ST9120821AS IDE1 Serial Number: 3PL0L3JL ATAPI Model Name: PIONEER DVD-RW DVR-K06RS System BIOS Version: V0.2303
VGA BIOS Version: ATi 009.012.001.015.000000 KBC Version:08.10 Serial Number:
2C30SK05C1619014B32500
Asset Tag Number: None Product Name: Manufacturer Name: Acer UUID: E0FB8AE073D1DA1192B700163647D4ED
F1 Help Esc Exit
↑ ↓ ←→
Parameter
50
Select Item
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub- Menu
F10 Save and Exit
Description
CPU Type
This item will show the CPU information of the system.
CPU Speed
This item will show the CPU clock speed.
IDE1 Model Name
This item will show the Model name of HDD installed on Primary IDE master. The hard disk model name is automatically detected by the system. If there is no hard disk present or unknown type, “None” should be shown on this field
IDE1 Serial Number
This item will show the Serial number of HDD installed on Primary IDE master. If no Hard disk or other devices are installed on Primary IDE master, then it will display a blank line
System BIOS Version
This field reports the BIOS version of system
VGA BIOS Version
This field reports the VGA version of the system
KBC Version
This field reports the keyboard controller version of the system
Serial Number
This item will show the Serial number of system.
Asset Tag Number
This item will show the Asset Tag number of the system.
Product Name
This field will show product name.
Manufacturer Name
This field will show manufacturer name.
UUID
This will be visible only when there is an internal LAN device present.
Chapter 2
