Hardware Specification and Configuration Processor Item
Specification
Type
AMD Turion
Feature
• AMD64 technology features uncompromising 64-bit and 32-bit performance • Vastly expands memory address ability with 40-bit physical addresses, 48-bit virtual addresses • Doubles the number of internal registers with eight additional (16 total) 64-bit integer registers and eight additional (16 total)128-bit SSE/SSE2/SSE3 registers • One 16-bit link supporting up to 1600MHz
TM
64 X2 dual-core TL-50/TL-52/TL-56/TL-60 processor
• Up to 6.4GB/s peak HyperTransportTM I/O bandwidth • Supports industry-standard widely-available PC2-3200 (DDR2-400), PC24200 (DDR3-533), PC2-4300 (DDR2-533), and PC-5300 (DDR2-667) unbuffered SODIMMs • Up to 10.7GB/s memory bandwidth • Dual channel, 128-bit interface On-die second (L2) cache
• TL-52/TL-56/TL-60: 512KB • TL-50: 256MB
System Main Chipset Item
Specification
Core logic
ATi RX485 + ATi SB460
System clock
ICS ICS951462
BIOS ROM
SST 39VF080
VGA
ATi M56P VGA controller with VRAM 256MB
KBC
NSPC97551
PCMCIA & IEEE 1394 & Memory card reader
TI7412
Super I/O
NSPC87383
IR
Vishay TFU6102F
Audio Codec & Amplifier
Realtek ALC883D Azalia Codec and Amplifier Maxim MAX9710
LAN
Broadcom 5788MG
North Bridge Item
Specification
Chipset
ATi RX485
Package
Micro-FCBGA 465-pin
Feature
• • • •
Chapter 1
Processor host bus support Integrated SDRAM controller up to 4GB (2 SODIMMs support) Integrated SDRAM clock buffer, 2 SODIMMs support External Graphics interface for PCI Express Architecture support
39
