32—REAR AXLE

CHRYSLER SERVICE MANUAL

12. REMOVAL OF AXLE DRIVE PINION FROM CARRIER (ALL MODELS) a. Removal

With carrier assembly mounted in stand, remove companion flange retaining nut and washer. On all models, remove drive pinion flange with utility puller Tool C-549, as shown in Figure 27. Remove pinion shaft oil seal. Use Tool DD993 to remove drive pinion oil seal from differential carrier assembly. (Refer to Fig. 28). Remove the oil slinger, bearing cone, spacer and shims (if so equipped), pinion adjusting washer, bearing cone and pinion from carrier housing. To remove or install the rear bearing from (or on) drive pinion, use special Tool DD-914 (for Model C-70) and Tool C-293-C for all other models (Fig. 29). NOTE When using Tool C-293-C, use Number 36 ninths also. nlfirk. plates

Remove both bearing cups from carrier assembly with a suitable drift. Be sure to drive both cups out evenly. b. Cleaning and Inspection

Clean all parts thoroughly in a suitable solvent and blow dry with compressed air. Remove any chips or foreign material from carrier housing. Inspect all machined surfaces for nicks, burrs or scratches. Inspect thrust shoulders in carrier housing (bearing cups) to make sure there are no burrs on them. The thrust shoulCROSS BORE TUBE

TOOL—CROSSBORE TUBE AXLE DRIVE PINION ADJUSTING WASHER OR SHIMS AXLE DRIVE PINION BEARING SPACER AXLE DRIVE PINION BEARING ADJUSTING SHIMS TOOL—COMPRESSION SLEEVE TOOL—COMPRESSION NUT

TOOL—CENTRALIZING WASHER/ AXLE DRIVE PINION BEARINGS / J TOOL—MAIN BODY TOOL—GAUGE BLOCK 4 9 x $10 Fig. 31—Main Body, Bearings, Spacer and Shims Installed (Tool C-758-D2)

der must be flat so the bearing cups will seat properly. CAUTION Do not rotate bearings with air pressure when blowing them dry, as damage to bearings may result from this practice.

Check bearings for roughness, or brinelling. The bearings must run free and show no indication of roughness or wear. Clean carrier housing thoroughly, inspect oil passages and inside of housing for burrs, grit or dirt. 13. INSTALLATION OF DRIVE PINION BEARING CUPS

Place bearing cups in position in carrier. Refer to Figs. 30 and 31 and proceed as follows:

DRIVE PINION REAR BEARING CONE

COMPRESSION SLEEVE

SP-1730 SLEEVE

WRENCH GAUGE "BLOCK

49 x 621

Fig. 30-Special Tool Set C-758-D2

52x379 Fig. 32—Bearing Installed on Tool
