Maintenance This chapter contains general technical information and instructions on how the prescribed maintenance items must be carried out. Read through the instructions carefully before starting work. The times when maintenance items must be carried are indicated in the Maintenance Schedule page 67. Read through the safety precautions for maintenance and service in the Safety Information page 4 chapter before work on the engine is begun.
WARNING! Care and maintenance work should be done with the engine stopped unless otherwise specified. Stop the engine before opening or removing the engine hatch/hood. Make it impossible to start the engine by removing the start key and cutting the system voltage with the main switches. D3 with SX/DPS sterndrive 1
2
3 4
5
6
9 8
1 2 3 4 5 6 7 8 9
Oil filler cap, engine Turbo Air Filter Coolant filler cap Seawater filter Crankcase ventilation Seawater Pump Charge air cooler Oil Cooler
10 11 12 13 14 15 16 17 18 19 20 21 22 23
Relays Oil Filter Auxiliary stop Fuel feed Fuel Filter Oil dipstick, drive Trim cylinder Sacrificial Anode Oil draining (behind propeller) Seawater intake Sacrificial Anode Heat exchanger Oil dipstick, engine Alternator
7
P0011340
70
47701352 04-2011
