Maintenance

This chapter contains general technical information and instructions on how the prescribed maintenance items must be carried out. Read through the instructions carefully before starting work. The times when maintenance items must be carried are indicated in the Maintenance Schedule page 67 Read through the safety precautions for maintenance and service in the Safety Information page 4 chapter before work on the engine is begun.

WARNING!

Care and maintenance work should be done with the engine stopped unless otherwise specified. Stop the engine before opening or removing the engine hatch/hood. Make it impossible to start the engine by removing the start key and cutting the system voltage with the main switches.

10

Engine, General

General inspection

Make a habit of visually checking the engine and engine bay before starting, and after operations when you have stopped the engine. This will help you to discover abnormalities quickly, or if something is about to happen.

Look especially carefully for oil, fuel and coolant leakages, loose bolts, worn or poorly-tensioned drive belts, loose cable connections, damaged electrical cables and hoses. This inspection only takes a few minutes and can prevent serious malfunctions and expensive repairs.

WARNING!

Accumulations of fuel, oil and grease on the engine or in the engine room is a fire hazard and must be removed immediately they are detected.

WARNING!

Ifanoil,fuelorcoolantleakisdetected,thecausemust beinvestigatedandthefaultrectifiedbeforetheengine is started.

Never direct the jet from a high-pressure washer at seals, rubber hoses or electrical components. Never use the high pressure setting for engine cleaning.

P0011619

Crankcase Ventilation, Filter Change

1Undo the four cover bolts.

2 Move the cover forward/up so that the hose comes loose from the air filter housing.

3Remove the filter and insert a new one.

4 Slide the hose back into the air filter housing. Screw the cover back in place.

IMPORTANT!

Scrap the old filter; it may not be cleaned.

Air Filter, Change

1Remove the engine cover attached by three bolts.

2Remove the hose clamp (1). Remove the filter by moving it above the crankcase ventilation union and then working it loose. Be careful to prevent contamination from entering the engine.

P0009040

Drive Belt, Check and Change

WARNING!

Stop the engine before doing any maintenance work.

Check belt tensions and condition regularly. The drive belts have automatic belt tensioners and do not need to be adjusted. Check that the belt tensioner does not bottom.

IMPORTANT!

Always replace a belt that appears worn or is cracked. Belts working in tandem must be replaced simultaneously.

Replacing drive belts

1Remove the protective cover (accessory) over the drive belts, where fitted.

2Turn the belt tensioner (1) out of the way and remove the drive belt. The belt tensioner can be locked in its bottom position with the aid of a screwdriver to facilitate belt replacement.

Repeat the procedure with the other belt (2).

3Install the new drive belts.

4Check that the drive belts are positioned correctly in the grooves.

5Replace the protective cover (accessory) over the drive belts.

Checking exhaust line

The exhaust line must be checked annually for corrosion between the hose and the pipe.

WARNING!

Risk of water entering. The exhaust line must be inspected while the boat is on land. In case of serious corrosion damage, the pipe must be repaired or replaced with a new one.

1Undo the hose clamps and remove the bellows.

2Check the contact surface. The pipe must be repaired or replaced if there is serious corrosion damage.
