In Case of Emergency
Starting Using Auxiliary Batteries WARNING! Explosion hazard. Batteries contain and give off an explosive gas which is highly flammable and explosive. A short circuit, open flame or spark could cause a violent explosion. Ventilate well.
WARNING! Never confuse the positive and negative poles on the batteries. Risk of arcing and explosion. P0002107
1 Check that the auxiliary battery has the same voltage as the engine system voltage. 2 Connect the red positive cable to the plus (+) terminal on the discharged battery and then to the plus terminal on the auxiliary battery. 3 Connect the black start cable to the minus (–) terminal on the auxiliary battery and to a place a little distance away from the discharged battery, e.g. the start motor's negative terminal.
WARNING! Under no circumstances may the black jumper cabel (–) come in contact with the positive connection on the starter motor. 4 Start the engine and let it run at fast idle for approximately 10 minutes to charge the batteries. Make sure there is no extra equipment connected to the electrical system.
WARNING! Working with or going close to a running engine is a safety risk. Watch out for rotating components and hot surfaces.
WARNING! Do not touch the connections during the start attempt: Risk of arcing. Do not bend over any of the batteries either. 5 Turn off the engine. Remove the start cables in the exact opposite order to their connection.
64
47701352 04-2011
