Instruments and Controls This chapter describes the instruments, panels and controls Volvo Penta sells for your engine. If you would like to complement your instrumentation, or if your boat is equipped with instruments not described here, we ask that you contact your Volvo Penta dealer.
Ignition Lock The start keys are supplied with a plate bearing the start code to be used when ordering spare keys. Keep the code beyond the reach of unauthorized people. S = 0 = I = II = III =
The stop position. The key can be inserted or removed. Operating position. System power is connected. Not used. Start position. Starter motor is engaged.
There is always a main helm station on a boat. It is the only helm station with an ignition lock. The ignition must be switched on here in order for other helm stations to be used. Read the starting instructions in the Starting page 45 chapter to make sure you use the correct start procedure.
Control Panels Volvo Penta panels and gauges can be installed in different combinations. There is always one information panel per driveline and helm station if no 7" screen is installed. The control panels can be used together with the tachometer and other accessory equipment.
