Information Menu PhoenixBIOS Setup Utility . Info.
Main
CPU Type: : CPU Speed :
Advanced
Security
Intel(R) Pentium (R) M CPU 2000 MHz
Boot
000
Exit
@ 2.00GHz
HDD Model Name: ST98823AS HDD Serial Number: 3PK016YX ATAPI Device: HL-DT-ST DVDRAM GSA-4082N System BIOS Version: v2.002e VGA BIOS Version: ATi 009.012.001.000 KBC Version:
V.1A17
Serial Number:
LXT123ZC1000420076EF00
Asset Tag Number: Product Name: Manufacturer Name:
TravelMate 8200 Acer
UUID:
004CEEEDBC630010AC3AFFFFFFFFFFFF
F1
Help
Esc Exit
↑ ↓ ←→
Select Item
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub- Menu
F10 Save and Exit
T
HDD Model Name:
T
This item will show the Model name of HDD installed on Primary IDE master. The hard disk model name is automatically detected by the system. If there is no hard disk present or unknown type, “None” should be shown on this field. HDD Serial Number:
T
This item will show the Serial number of HDD installed on Primary IDE master. If no hard disk or other devices are installed on Primary IDE master, it will display a blank line. UUID: It shows only when an internal LAN device is available.
NOTE: Other items are unit dependent.
52
Chapter 2
