Features The features of Travelmate 8200 are itemized as below:
Platform Intel® CentrinoTM Mobile Technology features: T
Intel® Pentium® M Yonah (dual core) processor 20/30/40/50/60 (2MB L2 cache, 1.66/ 1.83/2.0/2.16/2.33 GHz, 667 MHz FSB)
T
Intel® 945PM (Calistoga) Express Chipset with ICH7M-DH
T
Wireless solution: integrated Intel® PRO/Wireless 3945 ABG network connection (dualband tri-mode 802.11a/b/g) Wi-Fi CERTIFIEDTM solution, Acer SignalUp wireless technology support
Memory T
256/512MB or 1GB of DDR2 533/667 memory, Upgradeable to 2GB for 32bit OS, 4GB for 64bit OS by using two SODIMM modules
Display and Graphics T
15.4” WSXGA + TFT LCD, 1680 x 1050 pixel resolution (262K colours), simultaneous multi-window via Acer GridVista support
T
ATI M56P with 128/256MB of DDR video RAM, ATI POWERPLAYTM 5.0, Microsoft® DirectX® 9.0 and PCI ExpressTM support
T
Dual ViewTM support
T
External resolution / refresh rate • 2048 x 1536: 60/66/70/75/85 Hz • 1600 x 1200: 60/70/85/100/120 Hz • 1280 x 1024: 60/70/75/85/90/100/120/150/160/200 Hz • 1024 x 768: 60/70/72/75/85/90/100/120/160/200 Hz • 800 x 600: 60/70/72/75/85/90/100/120/160/200 Hz
T
MPEG-2 / DVD hardware-assisted capability
T
S-video / TV-out (NTSC / PAL) support
T
DVI-D (true digital video interface) support
T
Camera • 1.3 Megapixel high resolution CMOS • Streaming video indicator • MSN 7.0 full screen support • With face tracking and RightLightTM Technology
Storage
2
T
60/80/100/120 GB 5400 rpm SATA hard disk drive
T
Serial ATA with Native Command Queuing (NCQ) support
T
Acer DASP2 with HDD protection technology
T
AcerMedia Bay for hot-swappable optical drive modules
Chapter 1
