Part Three of Top View
Item
Description
Item
Description
CN20
SVIDEO
CN32
RTC battery connector (two pin)
CN21
Docking
CN33
HDD connector (22 pin SATA)
CN22
DVI-D
CN37
Connector SMD FFC 30 pin
CN23
CRT connector
CN38
Bluetooth module connector (five pin)
CN24
mini card connector
U37
V-RAM
CN25
RJ45 W/ LED
U40
V-RAM
CN26
Battery connector (seven pin)
U41
VGA chip
CN28
Fan connector
U43
CPU
CN29
Media connector (M/B side)
U44
North bridge
CN30
DDR2 (9.2MM)
U48
South bridge
CN31
DDR2 (5.2MM)
U57
BIOS
