Hardware Specifications and Configurations Processor Item
Specification
CPU type
Intel® Core™2 Duo Mobile Processor T7300/T7500/T7700 (4 MB L2 cache, 2/2.2/2.4 GHz, 800 MHz FSB), or T7100 (2 MB L2 cache, 1.8 GHz, 800 MHz FSB) Intel® Core™2 Duo Mobile Processor T7200/T7400/T7600 (4 MB L2 cache, 2/2.16/2.33 GHz, 667 MHz FSB), T5500/T5600 (2 MB L2 cache, 1.66/1.83 GHz, 667 MHz FSB) or T5200/T5300 (2 MB L2 cache, 1.60/1.73 GHz, 533 MHz FSB) Intel® Core™ Duo Mobile Processor T2250/T2350/T2450 (2 MB L2 cache, 1.73/1.86/2 GHz, 533 MHz FSB) Intel® Celeron® M processor 520/530 (1 MB L2 cache, 1.6/1.73 GHz, 533 MHz FSB) Intel® Celeron® M processor 440 (1 MB L2 cache, 1.86 GHz, 533 MHz FSB)
Core logic
Mobile Intel® PM965/GM965 + ICH8M Express Chipset
CPU package
Socket M (FCPGA6)
CPU core voltage
1.0375V to 1.3V
CPU Fan True Value Table DTS(degree C)
Fan Speed (rpm)
Acoustic Level (dBA)
45-50
0-3000
29
55-66
0-3300
33
68-74
3300-3800
38
78-83
3800-4100
40
86-91
4100-4800
40
Throttling 50%: On= 99 ° C; OFF=93 ° C OS shut down at 105 ° C; H/W shot down at 110 ° .C BIOS Item
30
Specification
BIOS vendor
Phoenix
BIOS Version
1.02 (MP version)
BIOS ROM type
SST/AMD 1MB CMOS Boot Block Flash Memory
BIOS ROM size
1M byte FLASH ROM SST
BIOS package
10-lead TSOP (10mmx20mm)
Supported protocols
ACPI 1.0b/2.0/3.0 compliance, PCI 2.2, System/HDD Password Security Control, INT 13H Extensions, PnP BIOS 1.0a SMBIOS 2.4, BIOS Boot Specification, Simple Boot Flag 1.0, Boot Block, PCI Bus Power Management Interface Specification, USB Specification 1.1/2.0, IEEE 1394 1.0, USB/1394 CD-ROM Boot Up support, PC Card Standard 1995 (PCMCIA 3.0 Compliant Device), IrDA 1.0, Intel AC97 CNR Specification, WfM 2.0, PXE 2.1, Boot Integrity Service Application Program Interface (BIS) 1.0, PC99a and Mobile PC2001 Compliant
BIOS password control
Set by setup manual
