Removing the VGA Module 1. Remove the mainboard. See “Removing the Mainboard” on page 79. 2. Remove the two securing screws from the VGA Module.
Step VGA Module
Size M2*4-NI (NL)
Quantity
Screw Type
2
3. The VGA module lifts automatically from the mainboard. Remove the VGA Module as shown.
