Power The Power screen allows the user to configure various CPU and power management options and device wakeup behavior.
Information
Main
InsydeH20 Setup Utility Advanced Security Power Boot
XAdvanced CPU Control XPlatform Power Management ACPI S3: W ake on PME W ake on Modem Ring Auto wake on S5 Quickly S4 Resume
F1 Help ESC Exit
Rev. 3.5 Exit Item Specific Help These items control various CPU parameters.
[Enabled] [Enabled] [Enabled] [Disabled] [Disabled]
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSubMenu
F9 Setup Default F10 Save and Exit
The table below describes the items, menus, and submenus in this screen. Settings in boldface are the default and suggested parameter settings. Parameter Advanced CPU Control
Chapter 2
Description Enter the Advanced CPU Control menu.
Submenu Items • • • • • • • • • • • • • • • • • • • • • •
P-States (IST) Boot performance mode Thermal Mode CMP Support Use XD capability VT Support C-States Enhanced C-States C-State Pop Up Mode C-State Pop Down Mode C4 Exit Timing Mode DeepC4 Hard C4E Enable C6 EMTTM Bi-directional PROCHOT# Dynamic FSB Switching Turbo Mode ACPI 3.0 T-States DTS DTS Calibration Thermal Trip Points Setting (Fan On Temp., Throttle On Temp.) 33
