Hardware Specifications and Configurations Processor Item
Specification
CPU type
Intel Cantiga GM / PM FSB: 667 / 800 / 1066 MHz Intel Cantiga GL FSB: 667 MHz
Core logic
Intel® Core™2 Duo mobile processor, supporting Intel® 64 architecture
CPU package
Micro uPGA-478 Package
CPU Fan True Value Table CPU Temperature Core 0
Core 1
Fan Speed (RPM)
SPL Spec (dBA)
58
58
2500
29
66
66
3000
31
74
74
3400
34
85
85
3800
37
100
100
4200
40
•
Throttling 50%: On= 100°C; OFF=90°C
•
OS shut down at 105°C; H/W shut down at 96°C
BIOS Item
Specification
BIOS vendor
Insyde
BIOS Version
V1.00 (MP first release version; V1.07 latest version up to 0718.)
BIOS ROM type
Flash
BIOS ROM size
2MB
BIOS package
ACPI 2.0 compliance with Intel Speed Step Support C1, C2, C3, C4, C6 and S3, S4 for mobile CPU
Supported protocols
•
Support ISIPP
•
Support Acer UI
•
Support multi-boot
•
Suspend to RAM (S3)/Disk (S4)
•
Various hot-keys for system control
•
Support SMBUS 2.0, PCI2.3
•
Support PXE
•
Support Y2K solution
•
Support Win Flash Wake on LAN from S3
•
Wake on LAN form S4 in AC mode
•
System information
•
Support ASF 2.0
•
Support iTPM (GM / PM Sku)
Cache Item
18
Specification
Cache controller
CPU
Cache size
6MB L2 Cache on CPU
Chapter 1
