July 2017 Part Description Index The Part Description Index is an alphabetical index of all part descriptions included in this manual. The index shows what page(s) the part is used on. BOOM TUBE ASSY #3 /W SYM DECAL.....79 Boom Tube Three.....77 BOOT(BELLOWS),E-STOP,BLACK.....91 ( R e f . ) BOOT, ROCKER JOYSTICK 75565.....93 VALVE,SOLENOID,3POS4WAY,HYDAC....113 BOOT,BATTERY TERMINAL,RED.....37 BOOT,CABLE TERMINAL,LG,RED,2/0.....37 A BOOT,JOYSTICK.....93 BOOT,PLUG 3 WAY.....23 ACCUMULATOR,500 PSI,HYDAC.....113 BOOT,TOGGLE SWITCH,SHORT*.....91 ACTIVATOR,STEER SENSOR.....17 BOX,EMPTY (122915).....41 AIR CLEANER,CLAMP,CUM B3.3T.....55 BOX,INSTRUCTION STORAGE.....87 AIR CLEANER,CUMMINS B3.3T.....55 BRACKET, CAC INTAKE TUBE MOUNT.....53 AIR CLEANER,NELSON.....47 BRACKET, SUPPORT, EXH. CUM T3.....53 AIR FILTER, PRIMARY ELEMENT.....55 BRACKET,BULKHEAD.....67 AIR FILTER, SECONDARY ELEMENT.....55 BRACKET,CAC 2 TUBING MOUNT.....53 ALARM,AUDIO,SUPERBOOM*.....41, 91 BRACKET,CNTL BOX MOUNTING***.....31 ALTERNATOR.....53 BRACKET,CONTACT CLAMP***.....41 ALTERNATOR, DEUTZ,BF4L2011***.....51 BRACKET,HYD.ROTATOR MOUNT ***.....33 ARM,ANTI-ROTATION,SWIVEL***.....33 BRACKET,INTAKE MOUNT,CUM.....55 ASSEMBLY, MED. PRESS. FILTER,.....37 BRACKET,INTAKE TUBE SUPPORT.....55 ASSEMBLY,CARRIER.....23 BRACKET,PRECLEANER MNT B3.3T.....59 ASSEMBLY,FUEL TANK,240L.....39 BRACKET,RETURN FILTER.....31 ASSY, DOOR, FUEL TANK, SRV.....27 ASSY, LS, LOAD SENSE, ALC1000.....43, 45, BRACKET,STROBE.....29 BRACKET,SWITCH ROD MOUNT,PNTED...15 89 BRACKET,WIPER #0 COVER L.....81 ASSY, RAD/CAC, CUMMINS B3.3T.....53 BRACKET,WIPER #0 COVER R.....81 ASSY,DOOR,LEFT FRONT, SRV.....25 BRACKET,WIPER #0 L.....81 ASSY,DOOR,LEFT REAR, SRV.....25 BRACKET,WIPER #0 R.....81 ASSY,DOOR,RIGHT FRONT, SRV.....27 BRACKET,WIPER #1.....81 ASSY,DOOR,RIGHT REAR, SRV.....27 BRACKET,WIPER #2 R.....81 ASSY,TOP COVER,RT REAR, SRV.....27 BRACKET,WIPER #2L.....81 BRAKE DISC KIT,75090.....35 B BRAKE KIT.....19 B A C K U P BRAKE KIT,RWD 1700TB***.....21 RING,71.60X67.20X1.40PTFE(60334).....37 BRAKE,SWING DRIVE (111145).....35 BASE,WITHOUT CONTACTS.....41, 91 BREATHER PIPE, TD 2011L04I.....51 BATTERY 12V,AGM DC115-12,115AH.....37 BREATHER,RESERVOIR 3 MICRON***.....31, BATTERY CABLE.....31, 37 39 BATTERY CABLE,POSITIVE DEUTZ.....37 BUMPER,RUBBER.....87 BATTERY,12V GRP 4D,190 AH,DRY*.....37 BUMPER,RUBBER***.....25, 27, 89 BEARING KIT,RWD 1700TB***.....19, 21 BUMPER,RUBBER,.75 X .50H,STUD.....25, 27 BEARING KIT,TURNTBL.ROT.DRVHUB.....35 BUSHING,FLANGE, .375X.5.....75 BEARING TURNTABLE SEAL***.....33 BUTTON,PUSH,RED MUSHROOM Bearing, 1.5 x 2 x 1.81 inches.....83 HEAD.....41, 91 BEARING,1.25 ID X 1.5 OD X .75.....85 BEARING,1.25IDX1.5ODX1.00L.....79, 85 C BEARING,1.5IDX1.75ODX1.0L.....17 CABLE ASSEMBLY,EXTEND SET.....83 BEARING,1.5IDX1.75ODX1.5L,PTFE.....17 CABLE ASSEMBLY,RETRACT SET.....83 BEARING,1.75IDX2.00ODX1.50L.....17 CABLE SQUEEZE CONN.....87 BEARING,2.50IDX3.00ODX2.00L.....65, 71 CABLE TIE,STUD MOUNT (PCON).....91 BEARING,FL,0.75ID X 1 OD X .49.....89 CABLE TRACK, HORIZ. 37 LINKS.....67 BEARING,FL,1.25IDX1.5ODX1.25L.....57 CABLE TRACK, VERT. 139 LINKS.....77 BEARING,FL,1.5IDX1.75ODX1.10LG.....83 CABLE TRACK,STEEL 60 LINKS**.....67 BEARING,GARLOCK,12FDU12.....89 CABLE,BATTERY NEGATIVE.....37 BEARING,TURNTABLE.....33 CABLE,BATTERY POSITIVE.....37 BELT.....53 CABLE,BATTERY POSITIVE 73".....37 BLOCK,PLATFORM LID STOP.....87 CABLE,DOOR FRAME,ENGINE SID.....27 BOLT,CARRIAGE,1/4-20 X .5,G2.....69 CABLE,GROUND,79" W/PIGTAIL.....31, 37 BOLT,CARRIAGE,1/4-20 X .63,G2.....79 BOLT,CARRIAGE,1/4-20 X .75,G2.......67, 81, CAP, COOLANT RET SYS(60721).....37 CAP,520112-6.....133 85 BOLT,CARRIAGE,1/4-20 X 2.5,G2.......67, 77, CAP,DIAGNOSTIC NIPPLE......105–106, 109– 110, 123, 125–126, 129, 131, 133 79 CAP,FUEL,DIESEL,NON-VENT.....39 BOLT,FLANGE,1/2-13 X 1.75.....25 CAP,OIL FILLER,DEUTZ,DIESEL***.....51 BOOM #0 REST PAD.....65, 67, 71 BOOM TUBE ASSY #0 /W SYM DECAL.....65 CAP,RADIATOR,PERKINS/FORD.....53 BOOM TUBE ASSY #1 /W SYM DECAL.....71 CHANNEL, MOUNTING.....33
(
Part No. 226056
S-3800,S-3200
CHECK VALVE, DROP IN STYLE.....99 CIRCUIT BREAKER, 25 AMP.....37 CIRCUIT BRKR 15A TYPE 2 METAL....37, 47, 53 CLAMP, 3 INCH.....51 CLAMP, CABLE, SY VERT CBL TRK.....77 CLAMP, HOSE, SY VERT CBL TRK.....77 CLAMP,0.50,#8 X 1/4,RUB CUSH.....31 CLAMP,0.63,#10 X 1/4,RUB CUSH.....47 CLAMP,1.00,#16 X 1/4,RUB CUSH.....69, 73 CLAMP,1.00,#16 X 7/16,RUB CUSH.....31, 47, 67 CLAMP,3.0,#48 X 1/4,RUB CUSH.....55 CLAMP,5.38,#86 X 3/8,RUB CUSH.....59 CLAMP,CONST TRQ 2.25"-3.13"OD.....55 CLAMP,CONST TRQ 2.75"-3.63"OD.....55 CLAMP,HOSE,1.75.....17, 85 CLAMP,HOSE,3.00".....51, 59 CLAMP,HOSE,3.50.....17, 49, 59, 85 CLAMP,HOSE,5.00.....59 CLAMP,HOSE,6.50.....65, 71 CLAMP,HOSE,8.50 DIA***.....65, 71 CLAMP,HOSE,SIZE .25 TO .63.....37 CLAMP,MUFFLER, 2.50 INCH.....47, 49, 53 CLAMP,MUFFLER,CUM B3.3T.....55 CLAMP,MUFFLER,CUM B3.3T, 9"DIA.....55 CLEVIS YOKE-1/4-28,PLTD W/PIN.....47, 55 CLIP,LCD,GRND.CONTROL.....41 CLIP,SPRING,1/4-20 BLACK.....67 COIL#10 E-COIL,10V ZENER DIODE.....99 COIL,12VDC #10DTSCH IP69 ECOIL.....101 COIL,12VDC #8 DTSCH IP69 ECOIL.....101 COIL,62328/62330,SIZE 10,DIN*.....105–106, 109–110 COIL,62329,SIZE12,W/FRAME,DIN*.......106, 109–110 COIL,DIN,REXROTH DO3 VALVE.....105–106, 109–110 COIL,GREEN W/ 2 PIN CONNECTOR*.....95 COIL,PROPORTIONAL,62327,DIN...105–106, 109–110 COIL,PROPORTNL.62326,SIZE8,DIN.....105– 106, 109–110 COIL,SOLENOID,HYDAC MANIFOLDS.....113 COLLAR,JOYSTICK,CENTER.....93 CONN,090136-12-8.....121, 123 CONN,520120-16.....125–126 CONN,520120-20.....125–126 CONN,520120-24.....125–126 CONN,520120-4***....119, 121, 123, 125–126, 131, 133 CONN,520120-4-6***.....119, 121, 123, 129 CONN,520120-6-10.....131, 133 CONN,520120-8***....119, 121, 123, 125–126, 131, 133 CONN,520120-8-10.....125–126 CONN,520120-8-12.....121, 125–126 CONN,BULKHEAD,520601-6.....125–126 CONN,BULKHEAD,520601-8.....121, 131 CONN,BULKHEAD,520801,-4.....121 CONN,BULKHEAD,520801,-8.....121 CONN,LONG,520122-12***.....119, 121 CONN,LONG,520122-8.....119 CONN.MALE PIPE/ORFS-4.....33 CONN.SQZ,PG 11,.34-.47,W/ORING.....75 CONNECTOR, DEUTZ FUEL SHUTOFF*....51
139
