RG140, RG170, RG200 22-
Tandem drive Check oil level
MAINTENANCE
case
24-
Park grader on a level surface. Remove level plug (2) from each tandem case. The oil must be level with the oil level plug hole. Add oil until it is brought to the proper level. Install all plugs.
Transmission oil filter Change filter (F)
WARNING Never use gasoline, solvent or other flammable fluids to clean parts. Use authorized commercial, nonflammable, non-toxic solvents.
Clean filter and surrounding area. Then remove the filter housing (F), change the elements and gaskets. Clean the inside of the filter housing (F) and contact surface. Install the filter.
1- Oil filler plug 2- Oil level plug 3- Drain plug
23-
Tandem Check
wheel
shaft
bearings
There are four (4) lube points for each tandem. Lubricate with 14 to 20 grease shots.
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel. 84
