RG140, RG170, RG200
MAINTENANCE
17-
Wheel lean link (B) Lubricate There are two (2) lube points. Lubricate with 4 to 6 shots on each side.
19-
Drive
Engine drive belt Check belt
tensioner
Measure the belt deflection in the most open area between the pulleys. The maximum deflection allowed is from 9.5 to 12.7mm (3/8 to 1/2 in). Remove the drive belt using a 1/2 in square socket wrench handle, to release belt tension.
Wheel lean link
Engine drive belt Wheel lean link (AWD - OPT) 18-
Front wheel lean cylinder (D) Lubricate There are two (2) lube points. Lubricate with 4 to 6 shots on each side.
1- Water pump pulley 2- Crankshaft pulley 3- Square hole of 1/2 in (13 mm) 4- Belt tensioner 5- Alternator
Drive belt and tensioner inspection After removing, examine the belt for damages.
Front wheel lean cylinder
Front wheel lean cylinder (AWD - OPT) Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel. 82
