OPERATOR'S COMPARTMENT
9- BRAKE PEDAL This pedal actuates the service brakes. To stop the grader press down on brake pedal. NOTE: Do not make steep slope descents using only the service brake. Reduce the speed and apply the brakes. Select an appropriate speed, allowing total machine control. This will avoid brake heating, and will increase the life of its components.
RG140, RG170, RG200
2 - ARTICULATION LEVER Move the lever forward for left articulation or backward for right articulation until the desired articulation angle is achieved. Release the lever so that it returns to the neutral position. 3 - FRONT WHEEL LEAN LEVER
The accelerator/decelerator pedal is connected to the engine throttle controls. To accelerate the engine, press down on the toe and to decelerate press down on the heel of the pedal. When the pedal is released, the engine speed will return to the hand throttle setting.
The front wheel lean lever leans the front wheels to the left or to the right to maintain stability when grading or ditching and to reduce turning radius. Move the lever forward to lean the wheels to the left or backward to lean the wheels to the right. After reaching the desired position, release the lever so that it returns to the neutral position.
GROUP 3
4 - BLADE LIFT LEVER (RIGHT END)
Implement lever controls (right side).
This lever is used to lower or raise the right end of the blade. Move the lever forward to lower or backward to raise the blade. After reaching the desired height, release the lever so that it returns to the neutral position.
10- ACCELERATOR/DECELERATOR PEDAL
5 - WARNING FLASHER To activate the warning flasher press the button located on the right side of the frontal plastic console. To turn it off, press it again.
1 - CIRCLE SIDE SHIFT LEVER This lever is used to move the circle to the right or left. Move the lever forward to shift the circle to the left or backward to shift the circle to the right. After moving the circle to the desired position, release the lever so that it returns to the neutral position.
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel. 47
